ES7673Y Automatic screw Driving Robot
The PROMATION ES7673Y is a Dual-Slide Automatic Screw Driving Robot featuring a robust SCARA Robot Gantry; with industry leading process stability and accuracy. Complete with Input / Output Terminals, the system is integrated with a high-precision automatic screw driving system - designed to deliver constant torque through-out the assembly process.
Combined with the Automatic Screw Feeding System (Air Output Type) this system can continuously feed screws, maintain an accurate screw count, and prevent screws from being lost, mishandled, or improperly installed.
system specifications:
VOLTAGE: 100~240V AC
POWER: 250W
AXIS: 3-Axis SCARA
WORKING AREA:
ARM LENGTH: 600mm
Z-AXIS: 100mm
DOUBLE Y-AXIS: 600mm
MOVING SPEED:
X-AXIS 0.1~600mm/sec
Y-AXIS 0.1~600mm/sec
Z-AXIS 0.1~300mm/sec
REPEATABILITY:
X-AXIS ±0.02mm
Y-AXIS ±0.02mm
Z-AXIS ±0.02mm
DIMENSIONS: 1000mm x 1400mm x 2010mm
WEIGHT: TBD
